Block 4 This area is owned by the Military Department of Indiana and is a major portion of the present cantonment area. Some buildings remain in modified form. The only remaining Chapel is here, along with the new Museum.
Bldg. #	Designed Use (Name)	Type or Symbol	Drawing Number	Width	Length	SqFt	Stories	Cap.	Remarks
0401	Recreation Bldg.	FB-2	800-419	25	50	1250	1
0402	Administration. Int. Bn.	IBA-1	800-222		70	0	1
0403	Mess Hall, Officer	M-172	800-849	25	94	2350	1
0404	Bachelor Officer Quarters	BOQ-44	800-317	29.5	130	7670	2
0405	Bachelor Officer Quarters	BOQ-44	800-317	29.5	130	7670	2
0406	Bachelor Officer Quarters	BOQ-44	800-317	29.5	130	7670	2
0407	Officer's Day Room	ORBL-3	800-451	25	90	2250	1
0408	Administration	A-1000	ASP-579	25	110	2750	1
0409	Infirmary	I-2	800-1429	25	94	2350	1
0410
0410	Administration. Int. Bn.	IBA-1	800-222	25	70	1750	1
0411	Recreation Bldg.	RB-1	700-310	37	99	3663	1
0412	Post Exchange	E-3(M)	WGH-AE-64	50	144	7200	1
0413	Administration. Int. Bn.	IBA-1	800-222	25	70	1750	1
0414	Theater	TH-10388	800-500	76	185	14060	1
0415	Qtrs. Reg. C.O.	RCQ-1	800-308	29.1	30	873	1

0416	Chapel #6	CH-1	800-550	37	97.75	3616.75	1	83rd Division Chapel - 1942

0417	Co. Administration. Stor. Recn.	SA2-RB4	800-651 & 800-459	25	110	2750	1
0418	Barracks	BKS-74	800-443	29.5	90	5310	2
0419	Barracks	BKS-74	800-443	29.5	90	5310	2
0420	Barracks	BKS-74	800-443	29.5	90	5310	2
0421	Mess Hall	M-172	800-849 & PE 987.2	25	96	2400	1
0422	Co. Administration. Stor. Recrn.	SA2-RB4	800-661 & 800-460	25	130	3250	1
0423	Barracks	BKS-74(M)	WGH-16-2	29.5	90	5310	2
0424	Barracks	BKS-74(M)	WGH-16-2	29.5	90	5310	2
0425						0
0426	Mess Hall					0
0427	Mess Hall					0
0428						0
0429						0
0430						0
0431						0
0432						0
0433						0
0434						0
0435						0
0436						0
0437	Mess Hall					0
0438	Mess Hall					0
0439						0
0440						0
0441						0
0442						0
0443						0
0444						0
0445						0
0446						0
0447	Mess hall					0
0448	Mess hall					0
0449						0

0450	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0450							0
0451	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0452	Co. Administration. Stor. Recrn.	SA2-RB4		800-661 & 800-460	25	130	3250	1
0453	Co. Administration. Stor. Recrd.	SA2-RB4		800-661 & 800-460	25	130	3250	1
0454	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0455	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0456	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0457	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0458	Mess Hall	M-228		800-851	25	118	2950	1
0459	Mess Hall	M-228		800-851	25	118	2950	1
0460	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0461	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0462	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0463	Co. Administration. Stor. Recrn.	SA2-RB4		800-661 & 800-460	25	130	3250	1
0464	Co. Administration. Stor. Recrd.	SA2-RB4		800-661 & 800-460	25	130	3250	1
0465	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0466	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0467	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0468	Mess Hall	Combined M-228's		WGH-AE-2	95.1	118	11221.8	1
0469	Mess Hall						0
0470	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0471	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0472	Barracks	BKS-74(M)		WGH-16-2	29.5	90	5310	2
0473	Co. Administration. Stor. Recrd.	SA2-RB4		800-661 & 800-460	25	130	3250	1
0474	Co. Administration. Stor. Recrd.	SA2-RB4		800-661 & 800-460	25	130	3250	1
0475	Barracks	BKS-74(M)		WGH-16-2	29.50	90	5310	2
0476	Barracks	BKS-74(M)		WGH-16-2	29.50	90	5310	2
0477	Barracks	BKS-74(M)		WGH-16-2	29.50	90	5310	2
0478	Barracks	BKS-74(M)		WGH-16-2	29.50	90	5310	2
0479	Mess Hall	M-228		800-851 & PE 987.2	25	118	2950	1
0480	Mess Hall	M-228		800-851 & PE 987.2	25	118	2950	1
0481	Barracks	BKS-74(M)		800-443	29.5	90	5310	2
0482	Barracks	BKS-74(M)		800-443	29.5	90	5310	2
0483	Barracks	BKS-74(M)		800-443	29.5	90	5310	2
0484	Co. Administration. Stor. Recrd.	SA2-RB4		800-661 & 800-460	25	130	3250	1
0485	Co. Administration. Stor. Recrd.	SA2-RB4		800-661 & 800-460	25	130	3250	1
0486	Barracks	BKS-74(M)		800-442	29.5	90	5310	2
0487	Barracks	BKS-74(M)		800-442	29.5	90	5310	2		Class Room
0488	Barracks	BKS-74(M)		800-442	29.5	90	5310	2		Class Room
0489	Mess Hall	M-172		800-859 &PE987.2	25	94	2350	1
0490	Mess Hall	M-152		800-819	25	88	2200	1
0491	Barracks	BKS-74(M)		800-443	29.6	90	5328	2
0492	Barracks	BKS-74(M)		800-443	29.6	90	5328	2
0493	Co. Administration. Stor. Recrd.	SA2-RB4		800-661 & 80-459	25	110	2750	1
0494							0
0495	Gasoline, Pump House	OS-PE-1		7101-517.01	10.5	15	157.5	1		3 - 12,000 Gal Tanks, 10 Disp. Points
0496	Motor Repair Shop	SP-2		800-606	37	84	3108	1
April 2001
0497	Motor Repair Shop	SP-2		800-606	37	84	3108	1
North April 2001			South			East			West

4100	Grease Rack	2 Car	600-1026	9.3	84	781.2	1		(Structure)
4101	Grease Rack	2 Car	600-1026	9.3	84	0			(Structure)
4102	Wash Rack	5 Car	7101-348.01	25	60	1500	1		(Structure)
4103	Wash Rack	5 Car	7101-348.01	25	60	1500	1		(Structure)
4104	Storehouse	SH-9	800-664	25	108	2700	1		MUSEUM
								Current Museum
4105	Guard House, Unit	UGH-24	800-1007	25	70	1750	1
4106	Off. Day Room	ORBL-3	800-451	25	90	2250	1
4107	Co. Administration. Stor. Recrd.	sa2-rb4	700-376m & 700,383	25.5	106	2703	1
4108	Co. Administration. Stor. Recrd.	sa2-rb4	700-376m & 700,383	25.5	106	2703	1
4109	Co. Administration. Stor. Recrd.	sa2-rb4	700-376m & 700,383	25.5	106	2703	1
4110	Mess Hall	m-152	800-805	25	100	2500	1
4111	Co. Administration. Stor. Recrd.	SA2-RB2	800-661 & 800-459	25	110	2750	1
4112	Recreation/Gymnasium	RB-E-T	WGH-AE-18	161	101	16261	1
4118	Swimming Pool	"C"	701-190 & WGH-24-2	40	100	4000	1		(Structure)
4119	Concession Stand	Spec.	Job Nr. 511, Johnson & McKenney	24	45	1080	1
