Block 11 |
|||||||||||
| Bldg. # | Designed Use (Name) | Type or Symbol | Drawing Number | Size-Width | Size-Length | SqFt | Stories | Cap | Remarks | ||
| 1101 | Mess Hall | M-228 | 800-851 & PE 987.2 | 25 | 118 | 2950 | 1 | ||||
| 1102 | Bachelor Officer Quarters | BOQ-44(M) | 800-317 & PE 1053 | 29.5 | 136.3 | 8041.7 | 2 | ||||
| 1103 | Bachelor Officer Quarters | BOQ-44 | 800-317 | 29.5 | 136.3 | 8041.7 | 2 | ||||
| 1104 | Officer's day Room | ORBL-3 | 800-451 | 25 | 90 | 2250 | 1 | ||||
| 1106 | Chapel | CH-1 | 800-550 | 37 | 97.7 | 3614.9 | 1 | ||||
 |
Typical Chapel - 1 of 12 See Block 4 for photos of remaining Chapel |
||||||||||
| 1107 | Administration | A-5 | 800-210 | 25 | 60 | 1500 | 1 | ||||
| 1110 | Co. Storehouse & Recreation Bldg. | SA2-RB2 | 800-661 & 800-458 | 25 | 110 | 2750 | 1 | ||||
| 1111 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1112 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1113 | Mess Hall | M-152 | 800-849 & PE 987.2 | 25 | 88 | 2200 | 1 | ||||
| 1114 | Co. Storehouse & Recreation Bldg. | SA2-RB2 | 800-458 & 800-661 | 25 | 110 | 2750 | 1 | ||||
| 1115 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1116 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1117 | Mess Hall | M-112 | 800-847 | 25 | 72 | 1800 | 1 | Class Room | |||
| 1118 | Mess Hall | M-112 | 800-847 & PE 987.2 | 25 | 72 | 1800 | 1 | ||||
| 1119 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1120 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1121 | Co. Storehouse, Administration. & Recreation Bldg. | SA2-RB2 | 800-661 & 800-458 | 25 | 110 | 2750 | 1 | ||||
| 1122 | Co. Storehouse, Administration. & Recreation Bldg. | SA2-RB2 | 800-661 & 800-458 | 25 | 110 | 2750 | 1 | ||||
| 1123 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1124 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1125 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1126 | Mess Hall | Combined M-172s | 800-443 | 90 | 90 | 8100 | 1 | 1126 & 1127 Combined | |||
| 1128 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1129 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1130 | Co. Storehouse, Administration & Recreation Bldg. | SA2-RB2 | 800-458 & 800-61 | 25 | 110 | 2750 | 1 | ||||
| 1131 | Co. Storehouse, Administration & Recreation Bldg. | SA2-RB2 | 800-458 & 800-61 | 25 | 110 | 2750 | 1 | ||||
| 1132 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1133 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1134 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1135 | Mess Hall | M-172 | 800-849 & PE 987.2 | 25 | 94 | 2350 | 1 | ||||
| 1136 | Mess Hall | M-172 | 800-849 & PE 987.2 | 25 | 94 | 2350 | 1 | ||||
| 1137 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1138 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1139 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1140 | Co. Storehouse, Administration & Recreation Bldg. | SA2-RB2 | 800-448 & 800-661 | 25 | 110 | 2750 | 1 | ||||
| 1145 | Gas Sta. Pump House | GS-PH | 7101-517.01 | 10.5 | 15 | 157.5 | 1 | 2-12,000 gal tnks, 10 Disp Points | |||
| 1147 | Grease & Inspection Rack | 2 car | PE 851 | 9.3 | 114 | 1060.2 | 1 | (Structure) | |||
| 1149 | Grease & Inspection Rack | 2 car | PE 851 | 9.3 | 114 | 1060.2 | 1 | (Structure) | |||
| 1150 | Wash Rack | 5 car | 7101-348.01 | 25 | 60 | 1500 | 1 | (Structure) | |||
| 1151-3 | Gas Sta & Pump House | GS-PH | 7101-517.01 | 10.5 | 15 | 157.5 | 1 | 2-12,000 gal tanks, 7 Disp Points | |||
| 1154 | Motor Repair Shop | SP-2 | 800-606 | 37 | 84 | 3108 | 1 | ||||
| 1155 | Motor Repair Shop | SP-2 | 800-606 | 37 | 84 | 3108 | 1 | Hoosier Horse Park stables | |||
 |
 |
 |
 |
||||||||
| 1156 | Motor Repair Shop | SP-2 | 800-606 | 37 | 84 | 3108 | 1 | Hoosier Horse Park stables | |||
 |
 |
 |
 |
||||||||
| 1157 | Motor Repair Shop | SP-2 | 800-606 | 37 | 84 | 3108 | 1 | Hoosier Horse Park stables | |||
 |
 |
 |
 |
||||||||
| 1158 | Motor Repair Shop | SP-2 | 800-606 | 37 | 84 | 3108 | 1 | Hoosier Horse Park stables | |||
 |
 |
 |
 |
||||||||
| 1159 | Motor Repair Shop | SP-14 | 700-1390 | 76.1 | 240 | 18264 | 1 | ||||
| 1160 | Motor Repair Shop | SP-14 | 700-1390 | 76.1 | 240 | 18264 | 1 | ||||
| 1161 | Motor Repair Shop | SP-14 | 700-1390 | 76.1 | 240 | 18264 | 1 | ||||
| 1162 | Motor Repair Shop | SP-14 | 700-1390 | 76.1 | 240 | 18264 | 1 | ||||
| 1164 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1165 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1166 | Barracks | BKS-74 | 800-443 | 29.5 | 90 | 5310 | 2 | ||||
| 1167 | Co. Storehouse, Administration & Recreation Bldg. | SA2-RB2 | 800-458 & 800-661 | 25 | 110 | 2750 | 1 | ||||
| 1168 | Mess Hall | M-152 | 800-849 & PE 987.2 | 25 | 88 | 2200 | 1 | ||||
| 1169 | Grease & Inspection Rack | 2 car | PE 851 | 9.3 | 114 | 1060.2 | 1 | (Structure) | |||
| 1171 | Grease & Inspection Rack | 2 car | PE 851 | 9.3 | 114 | 1060.2 | 1 | (Structure) | |||
| 1172 | Unit Guard House | UGH-24(M) | 800-1007 | 25 | 70 | 1750 | 1 | Family Qtrs | |||
 |
 |
 |
 |
||||||||
| 1173 | Storehouse | SH-8 | 800-663 | 25 | 54 | 1350 | 1 | ||||
| 1177 | Dispatch House | DH-1 | 800-305 | 14 | 16 | 224 | 1 | Nursery Play | |||
| 1178 | Ordnance Oil Storage | Spec | PE 1029 | 29.75 | 60 | 1785 | 1 | ||||
| 1179 | Oil Storage House | Concrete | 20 | 20 | 400 | 1 | |||||
