| Block 9
This area is operated by the Johnson County parks Department and their headquarters is here. This was the Post Warehouse area and all trains un-loaded cargoes here. |
||||||||||
| Bldg. # | Designed Use | Type | Drawing | Width | Length | Sq. Ft. | Stories | Remarks | ||
| 0901 | Laundry | Ldy20000A | 800-1029 | 234.5 | 270.5 | 63432.25 | 1 | 20,000 pcs. 44 hr. | ||
| 0902 | Clothing Equip. Repair | CERS-1 | 800-1001 & CA 32-4 | 60 | 156.8 | 9408 | 1 | |||
 |
||||||||||
| 0904 | Bakery | BAK-3 | 800-682 | 98 | 126 | 12348 | 1 | 22,500# 16 hr. | ||
| 0905 | Administration | A-9 | 800-210 | 25 | 100 | 2500 | 1 | |||
| 0906 | Office, QM | PQM-1 | 800-201 | 71 | 136 | 9656 | 1 | |||
| 0907 | Office, QM | PQM-1 | 800-201 | 71 | 136 | 9656 | 1 | |||
| 0908 | Administration | A-10 | 800-210 | 25 | 110 | 2750 | 1 | |||
| 0909 | Fire Station #1 | F-2 | 800-800 | 44 | 107 | 4708 | 1 | |||
 |
 |
 |
 |
|||||||
| 0911 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0912 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0914 | Gas, Sta. Bulk Plant | GS-BP | 800-601 | 10.5 | 15 | 157.5 | 1 | 3-12,000 gal tanks, 1 Tnk trk outlet | ||
| 0915 | Motor Repair Shop | A-OD | 652-541 | 60 | 100 | 6000 | 1 | Post Engr. Hvy E. | ||
|
|
Mar 2000 Owned by DNR 10 ton overhead crane. Used upstairs North room with blue glass to work on tank gun sights. Tall target on pole far to the North |
|
||||||||
| 0916 | Boiler House, for A-OD | 652-563 | 26.3 | 26.3 | 691.69 | 1 | ||||
|
|
Mar 2000 Owned by DNR. |
|
||||||||
| 0917 | Warehouse, Gen'l | SH-13(M) | 800-652 | 60 | 150 | 9000 | 1 | Packing & Crating | ||
| 0918 | Ramp, End & Side loading | PE 831.1 | 148 | 30 | 4440 | 1 | (Structure) | |||
| 0920 | Repair Shop | A-10 | 800-210 | 25 | 110 | 2750 | 1 | Post Engr. Shop | ||
| 0921 | Warehouse, Gen'l | SH-18 | 800-654 | 60 | 150 | 9000 | 1 | |||
| 0922 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0923 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0924 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0925 | Warehouse, Gen'l | SH-18 | 800-654 | 60 | 150 | 9000 | 1 | |||
| 0926 | Warehouse, Gen'l | SH-18(M) | PE 943 | 60 | 150 | 9000 | 1 | Commissary | ||
| 0927 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0928 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0929 | Cold Storage Bldg. | CS-30(M) | CA-45-2 & PE 886 | 87.5 | 278.1 | 24333.75 | 1 | |||
| 0930 | Warehouse, Gen'l | SH-18(M) | CA-45-2 | 60 | 150 | 9000 | 1 | Pastry Shop | ||
| 0931 | Warehouse, Gen'l | SH-13(M) | 800-652 & CA 32-2 | 60 | 150 | 9000 | 1 | Q.M. Shop | ||
| 0932 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0933 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0934 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0935 | Warehouse, Gen'l | SH-18 | 800-654 | 60 | 150 | 9000 | 1 | |||
| 0936 | Warehouse, Gen'l | SH-18 | 800-654 | 60 | 150 | 9000 | 1 | |||
| 0937 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0938 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0939 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0940 | Warehouse, Gen'l | SH-18 | 800-654 | 60 | 150 | 9000 | 1 | |||
| 0941 | Warehouse, Gen'l | SH-18 | 800-654 | 60 | 150 | 9000 | 1 | |||
| 0942 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0943 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0944 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0945 | Warehouse, Gen'l | Sh-18 | 800-654 | 60 | 150 | 9000 | 1 | |||
| 0946 | Utility Shop | SP-11(M) | 7101-C-17 | 25 | 372 | 9300 | 1 | Post Engr Shops | ||
| 0947 | Shed | SD-18 | 700-373 | 25 | 84 | 2100 | 1 | |||
| 0948 | Shed | SD-18 | 700-373 | 25 | 84 | 2100 | 1 | |||
| 0949 | Administration | A-10(M) | 800-210 | 97 | 110 | 10670 | 1 | Post Engr Off. | ||
| Bldg 949 was later used as Post Headquarters when the Post began to down-size. |
|
Safe Door of Bldg. 949 - Administration. Now Johnson Cty Park Headquarters. Also once Post Headquarters when downsizing was taking place. | ||||||||
| 0950 | Warehouse, Gen'l | SH-19 | 800-654 | 60 | 150 | 9000 | 1 | |||
| 0951 | Laundry Steam Plant | LSP20000A | 800-1619A | 56 | 68 | 3808 | 1 | |||
| 0952 | Warehouse, Gen'l | SH-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0953 | Warehouse, Gen'l | sh-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0954 | Warehouse, Gen'l | sh-13 | 800-652 | 60 | 150 | 9000 | 1 | |||
| 0955 | Administration | A-9 | 800-210 | 25 | 100 | 2500 | 1 | |||
| 0956 | Shop | Spec. | 7101-c-16 | 40 | 126 | 5040 | 1 | P.E.Carp. Shop | ||
| 0957 | Shop | Spec. | 7101-c-16 | 30 | 84.4 | 2532 | 1 | P.E.Shop | ||
| 0958 | Shed | SD-18 | 700-373 | 25 | 47 | 1175 | 1 | P.E.Storage | ||
| 0964 | Shelter, Locomotive | Spec. | CA-11-5 & PE 1079 | 27 | 112 | 3024 | 1 | |||
| 0965 | Civilian Mess | Spec | PE 916 | 40 | 150.75 | 6030 | 1 |
model
railroaders Club house 2001 |
||
 |
 |
 |
 |
|||||||
| 0966 | Shop | Spec. | PE 397 | 20 | 70 | 1400 | 1 | |||
| 0972 | Dry Cleaning | Spec. | PE 709 | 38.3 | 62.3 | 2386.09 | 1 | |||
| 0978 | Paint Storage | ST-2 | E-78-OS-01 | 20 | 20 | 400 | 1 | |||
| 0979 | Ramp, End Loading | Spec | PE 831.1 | 34 | 50 | 1700 | 1 | (Structure) | ||
| 0980 | Ramp, End Loading | Spec | PE 831.1 | 14 | 50 | 700 | 1 | (Structure) | ||
| 0981 | Q.M. Oil Storage | Spec. | PE 960 | 20 | 30.75 | 615 | 1 | |||
| 0982 | Storage Shed | Spec. | 34 | 36.4 | 1237.6 | 1 | ||||
| 0983 | Storage Shed | Spec. | 18.1 | 30 | 543 | 1 | ||||
| 0985 | Reservoir for Laundry | Elev. | PE 1164 | 40,000 gal | 0 | (Structure) Steel, Elevated | ||||
| 0987 | Reservoir for Laundry | Underground | 7101-395.201 | 50,000 gal | 0 | (Structure) | ||||
